Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG

    Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers

    Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers
    • Buy cheap Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG from wholesalers

    Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : 300
    Certification : ISO,CE
    Price : negotiable
    Payment Terms : T/T,L/C,Western Union
    Supply Ability : 40 sets per month
    Delivery Time : 35 working days
    • Product Details
    • Company Profile

    Sweden Bearing Finished Wire Twisting Machine Range 19-32AWG

    Wire Twisting Machine Sweden Bearing Finished Wire Range 19-32AWG Cable Bunching Machine


    1. Application

    Application: Auto high speed twisting apply to copper wire twisting for computer flat cable,earphone cord, electronic wire,power wire, telephone cable, automotive cable, lane cable etc



    2. Specifications

    ModelHH-630HH-800HH-1000
    TwistingApply to over 7 threads silver plated wire, tin plated wire,enamelled wire, naked copper wire,CCS, CCA etc. Super fine conductor and cored wire twisting
    Finished Wire Range16-26 AWG16-26AWG16-26AWG
    Twisting Section0.80mm²-6mm²0.25mm²-10mm²1.50mm²-16mm²
    Diameter of Single Wire0.12mm-0.64mm0.38mm-1.0mm0.38mm-1.7mm
    Twisting Distance4.2mm-130mm22.51mm-155.32mm35mm-200mm
    Gross WeightMAX 400kgMAX 900kgMAX 1200kg
    Max High Axis Rotation Speed1800RPM(3600t/min)1200 RPM(2400t/min)800RPM(1600t/min)
    Twisting DirectionTo left or rightTo left or rightTo left or right
    Flat CablePolish rod traverse unit, pitch & throw adjustable
    Taking-up Tension TrackTension adjustable, pulled wire no deformation
    Machine Using BearingMain bearing made in Sweden, others in Japan
    Power10HP controlled inverter15HP Controlled inverter25HP Controlled inverter
    Noise LevelApprox 80dBApprox 75dBApprox 80dB
    Machine Dimension(mm)(L)2850*(W)1500*(H)1600(L)3673*(W)1550*(H)1650(L)4473*(W)2200*(H)2300
    Net WeightApprox4000kgApprox5000kgApprox8000kg


    3. Certificate


    4. Factory & Workshop &Warehouse


    Company nameHOOHA Co.,Ltd
    Established2013
    Main productsUpcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine and so on.
    Value added serviceInclude factory planning, cable raw material supply,cable equipment layout,cable technology export,technical support and operation training and cable testing laboratory construction.
    Factory locationHumen Town,Dongguan City,Guangdong province.
    Manufacturing Center4000 sqm
    ShowroomMore than 2000 sqm.

    5. Experenced team


    Team structureNumberExperience
    Pre-sale service team

    5 machine designer

    5 wire and cable engineers

    over 15 years
    Dedicated service team10 dedicated serviceover 8-10 years
    After sales team

    10electricity engineers

    8 mechanical Engineers

    5 software engineer

    over 10 years
    Production self-inspection team5 production self-inspection engineersover 15 years


    6. FAQ


    QuestionAnswer
    MOQ1 set
    Lead Time30~40 working days since starting producing.
    Warranty Time1-year quality guarantee for the machine
    Payment TermsT/T,L/C,Western Union
    Installation
    (3 choices )
    a. HOOHA's Chinese installation team.
    b. HOOHA's overseas installation co-partners in your country.
    c. DIY Guide: HOOHA supports online guidance.
    How to StartContact us and leave your contact email and phone number.

    7. Why us?


    HOOHA GROUP provide a series of solution for the layout design of cable plant, machine matching, shipping and installation. It means you only spend less money on machine and can enjoy such services and save time.


    1.We are the cable equipment manufacturer.

    2.Professional engineer team with long-term research and development in the field of cable equipment.

    3.Provides high frequency capacity manufacturing machines. Keep the machine running all day.

    4.Our machine use the international qualified brand components,like Siemens ,Omron,Nsk,lg etc

    5.Technical support and spare parts service.

    6.Rich experience in overseas technical training and operation training.

    7.Professional and responsible team to ensure efficient communication,help to save time and human cost for customers.

    8.Systematic experienced foreign trade team to ensure service quality.

    9.Working hard to meet customers’ needs.


    8. Contact us


    Add: 3 rd Floor, Building D, No.38 Houhu Road, Humen Town, Dongguan City, Guangdong Province,China
