PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm

    Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers

    Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers
    • Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers
    • Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers
    • Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers
    • Buy cheap PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm from wholesalers

    PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : CAT7
    Certification : CE, ROHS
    Price : USD 0.5/M
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 500 Million Meters Per Year
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    PVC LSZH LSOH PE HDPE Cat7 Network Lan Cable 0.56mm 0.64mm

    PVC LSZH LSOH PE HDPE Network Cable Cat7 Cable Communication LAN Cable


    1. Description


    ISO/IEC 11801 7 class /F class standard in the latest kind of twisted-pair wire, it is mainly to adapt to the application and development of megabit Ethernet technology.But it is no longer an unshielded twisted pair, but a shielded twisted pair, so it can provide a combined attenuation-to-crostalk ratio of at least 500MHz and an overall bandwidth of 600MHz, more than twice the Class 6 and Super Class 6 lines, with a transmission rate of up to 10Gbps.In the seven types of cables, each pair of wires has a shield layer, and four pairs of wires together have a common large shield layer.Physically, the additional shielding gives the seven types of wires a larger wire diameter.


    Another important difference is the ability to connect hardware. The parameters of the seven types of systems require that all line pairs provide at least 60dB of integrated near-end string winding at 600MHz of the connector.However, the super class 5 system only requires 43dB at 100MHz, and the value of class 6 at 250MHz is 46dB.




    2. Specification


    MODEL

    CAT7 LAN CABLE

    CONDUCTOR:

    BARE COPPER 23AWG

    INSULATION

    FOAM HDPE

    1ST LAYER

    ALUMINIUM FOIL PER PAIR

    2ND LAYER

    BC/CCA BRAIDING OVERALL

    JACKET

    PVC/LSZH


    3. Parameters


    Number of Conductors:8

    Priduct Type:sftp Cat7 cable

    classify:SFTP

    Conductor:Bare Copper

    Diameter:0.56mm/0.64mm

    Insulation:FPE

    Jacket: PVC LSZH LSOH PE HDPE

    Packing:2 reels /carton

    Specification:305m/1000ft per reel

    Color:Green Black Yellow White Blue

    Certification: CE, ROHS


    4.Packing


    1.Wooden reel, plastic reel,paper reel,carton box
    2.100m:PE protective layer, 5 roll per carton box
    3.305m:one roll in one carton box, two carton boxes in one master carton
    4.500m:wooden roll package, carton box as outer package



    5. Delivery


    LCL Delivery<50Rolls<100Rolls<500Rolls
    25 Days22 Days20 Days
    FCL Delivery1*20GP1*40GP1*40HQ
    15~18 Days15~18 Days15~18 Days


    6. Detailed Photos



    7. Application



    8. Choose HOOHA


    HOOHA GROUP provide a series of solution for the layout design of cable plant, machine matching, shipping and installation. It means you only spend less money on machine and can enjoy such services and save time.


    1.We are the cable equipment manufacturer.

    2.Professional engineer team with long-term research and development in the field of cable equipment.

    3.Provides high frequency capacity manufacturing machines. Keep the machine running all day.

    4.Our machine use the international qualified brand components,like Siemens,Omron,Nsk,lg etc

    5.Technical support and spare parts service.

    6.Rich experience in overseas technical training and operation training.

    7.Professional and responsible team to ensure efficient communication,help to save time and human cost for customers.

    8.Systematic experienced foreign trade team to ensure service quality.

    9.Working hard to meet customers’ needs.
