    Twisting Cable Bundling Machine , 500rmp Cantilever Cable Twisting Machine

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : 1000-1250
    Certification : CE ISO
    Price : negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20 sets/month
    Delivery Time : 35 working days
    • Product Details
    • Company Profile

    Twisting Cable Bundling Machine , 500rmp Cantilever Cable Twisting Machine

    Cantilever Twisting bunching Wire Machine With CE/ISO and High Speed

    500rmp Cantilever Twisting Cable Bundling Machine Cable Twisting Machine


    1. Application


    Auto high speed twisting machine apply to copper wire twisting for computer flat cable,earphone cord electronic wire,power wire,telephone cable, Automotive cable, lane cable etc.


    2. Specifications


    Machine model

    HH 1000

    HH1250

    Single wire OD(mm)

    Φ1.0-Φ5.0

    Φ1.0-Φ5.0

    Max stranding OD(mm)

    Φ25

    Φ30

    Traverse pitch(mm)

    3-30

    3-35

    Speed

    Max 500rpm

    Max 450rpm

    Twisting pitch(mm)

    20-400

    30-500

    Pay-off bobbin size(mm)

    Φ500-Φ630

    Φ500-Φ630

    Take-up bobbin size(mm)

    Φ1000

    Φ1250



    3. Brand of spare parts


    Motor: Siemens

    Inverter : available to Japan Yaskawa, Siemens, America Emerson

    Temperature Control Meter : Japan RKC, Omron

    PLC : German Siemens , Japan Misubishi

    Auxiliary Relay: Japan Omron

    Ammeter and Voltmeter: Taiwan Risesun

    Indicator, Switch and Button : Taiwan TEND

    Contactor: Taiwan Shihlin ,Schneider

    Relay: Japan Omron

    Line Speed Meter: Taiwan FOTEK/Yangming

    Bearing : NSK, SKF


    4. Delivery


    5. Team structure


    NameeducationPositionMainly responsible for projectSpecializing in projectIndustry working history
    zanyang XiecollegeGeneral EngineerThe total project design and planningpower cable machine15 years
    xioahua HucollegeVis general engineerThe total project design and planningnet cable,data cable machine10 years
    Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25 years
    xiuwu ChencollegeGeneral EngineerThe total project design and planningcopper drawing machine15 years
    lixin YuancollegeEngineerThe project design and planningcoppwer wire making technical16 years
    zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15 years
    jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7 years
    xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10 years
    changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10 years
    haipin LiUniversityEngineering directorMarketing and salesproject consulting8 years
    sen YangUniversityEngineering translatorMarketing and salesproject consulting5 years


    6. Company information


    Company nameHOOHA Co.,Ltd
    Established2003
    Main productsUpcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine and so on.
    Value added serviceInclude factory planning, cable raw material supply,cable equipment layout,cable technology export,technical support and operation training and cable testing laboratory construction.
    Factory locationHumen Town,Dongguan City,Guangdong province.
    Manufacturing Center4000 sqm
    ShowroomMore than 2000 sqm.


    7. FAQ


    QuestionAnswer
    MOQ1 set
    Lead Time30~40 working days since starting producing.
    Warranty Time1-year quality guarantee for the machine
    Payment TermsT/T,L/C,Western Union
    Installation
    (3 choices )
    a. HOOHA's Chinese installation team.
    b. HOOHA's overseas installation co-partners in your country.
    c. DIY Guide: HOOHA supports online guidance.
    How to StartContact us and leave your contact email and phone number.

    8. Choose Us


    HOOHA GROUP provide a series of solution for the layout design of cable plant, machine matching, shipping and installation. It means you only spend less money on machine and can enjoy such services and save time.


    1.We are the cable equipment manufacturer.

    2.Professional engineer team with long-term research and development in the field of cable equipment.

    3.Provides high frequency capacity manufacturing machines. Keep the machine running all day.

    4.Our machine use the international qualified brand components,like Siemens ,Omron,Nsk,lg etc

    5.Technical support and spare parts service.

    6.Rich experience in overseas technical training and operation training.

    7.Professional and responsible team to ensure efficient communication,help to save time and human cost for customers.

    8.Systematic experienced foreign trade team to ensure service quality.

    9.Working hard to meet customers’ needs.



    9. Contact us


    Add: 3 rd Floor, Building D, No.38 Houhu Road, Humen Town, Dongguan City, Guangdong Province,China


    Hongkong airport to Humen by boat 2 hours
    Guangzhou airport to Humen by car 2 hours
    Shenzhen airport to Humen by car 1 hour
    Guangzhou South high speed train station to Humen 20 minutes
    Shenzhen North high speed train station to Humen 20 minutes
