    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-1040
    Certification : Sira CE SGS
    Price : 72789 USD/ per set
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 60
    • Product Details
    • Company Profile

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Product Picture

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Introduction

    Project Name HH-1040 Automatic Shaking Pan Coating Machine
    Project introduction The products are automatically rolled into rolls, then enter the coating part for labeling + complete packaging, unpowered conveying line
    Application Flat cable wire
    Output MAX260m/min
    The rotating speed 930 RPM Max
    The production line 100m/roll
    Storage capacity No less than 200m

    Function

    1.Save labor, the whole section is automatic roll packaging, including belt line feeding, automatic roll, labeling and coating of products, realizing unmanned operation of the packaging process.

    2. The product packaging is consistent, the effect is beautiful, and the effect is many.

    Specification

    Model HH-1040
    Dimensions L3340*W1673*H1951mm
    Circle height 50-100mm
    Inner diameter of coiling Φ140-Φ160mm (fixed size) selected by the customer
    Maximum outer diameter of coiling φ400mm
    Arm holding method Servo holding arm
    Film loading method Pneumatic clamping
    Envelope height 50-90mm
    Packed coil weight <25kg
    Film material PVC/PE
    Film thickness 0.04mm-0.07mm
    Film size 40mm wide
    Label size width 50-70mm length 90mm-180mm
    Label material Plastic wrapping paper (guaranteed that the label is airtight)
    Applicable cable type Φ3-Φ8mm power cable (BV1.5-6mm², BVR2.5-10mm²)
    Power supply AC380V, three-phase, 50HZ (China) or specified by the customer
    Air source Compressed air pressure : 5-7kg/cm³
    Weight

    1800KG

    Layout Of Equipment

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Factory Picture

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Company Profile

    Our aim: To be a world-class supplier providing wire & cable manufacturing and using solution.
    Our vision: To make wire & cable manufacturing and using more humanized.
    Our target: More professional customer service, struggle for employees' dreams.
    We are a Hong Kong company, focusing on in-depth cooperation with Chinese leading manufacturers to provide advanced wire&cable solutions.

    Technical team

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire

    Chen Senior Engineer
    Machine design for 30 years

    Hu Machine Designer
    20 years engineering design experience

    Bi Head Engineer
    Responsible for project engineering
    Professional Engineers and Experienced Sales Team
    Name
    Education
    Position
    Mainly responsible for project
    Specializing in project
    Working history ( year )
    Zanyang Xie
    college
    General Engineer
    The total project design and planning
    power cable machine
    15
    Xiaohua Hu
    college
    Vis general engineer
    The total project design and planning
    net cable,data cable machine
    10
    Changhong Cheng
    college
    Engineer
    Drawings and after-sales service
    Teflon,Optical fiber cable machine
    25
    Xiuwu Chen
    college
    General Engineer
    The total project design and planning
    copper drawing machine
    15
    Lixin Yuan
    college
    Engineer
    The project design and planning
    coppwer wire making technical
    16
    Zhenghai Qiu
    college
    cable engineer
    After service
    cable making and cable factory management servie
    15
    Jinxin Liu
    college
    Marketing engineer
    After service
    electrical engineer
    7
    Xingguo Tang
    High school
    Electrical engineer
    After service
    electrical engineer
    10
    Changqiang Li
    High school
    Maintain engineer
    After service
    machina maintain and install service
    10
    Haipin Li
    University
    Engineering director
    Marketing and sales
    project consulting
    8
    Sen Yang
    University
    Engineering translator
    Marketing and sales
    project consulting
    5

    Customer Cases

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Dubai
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Algeria
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Syria
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Egypt
    Pre-sale
    1.Professional engineer team provide customized design and machine arrangement drawing service 2.Professional engineer team can
    visit customers's company in person and provide face-to-face service 3.Professional trading system provide high-efficient communication 4.Professional sales team including pre-sale staffs,after-sale staffs,order supervisor,shipping managers, finance
    managers,cable. making engineers would give you more detailed consultant service.
    Mid-sale
    1.Professional follow-up system ensures high-quality service including live production video shooting,etc. 2.Quality control system with professional engineers ensures project goes smoothly.
    3.Quality checking will be provided with professional quality
    inspection report before machine delivery.
    After-sale
    1.Overseas on-site installation guidance and technical support including previous testing, operation instruction and talent training.
    2.Free online consultance service. 3.Long-time maintenance, reconstruction and upgrade services of the overall equipment.
    4.Extend service support, such as raw material or accessory suggestions etc.

    Exhibitions and Certificates

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    2018 Bombay, India Fair
    Our company took part in Bombay Exhibition in 2018
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Russia Exhibition
    The communication of Russia exhibition
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    2019 Thailand Exhibition
    A successful interchange at the Exhibition in Thailand
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    2020 International Cable & Wire Fair
    The Shanghai exhibition is gain a lot
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Our Certificate

    Packing and Transportation

    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Carton package
    wooden package
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Wrap in plastic film to prevent wetting
    Full Automatic Unmanned Operation Packing Coiling Coating Machine For Flat Cable And Wire
    Container transportation

    1. film packing 2. wooden package 3.enclosed wooden package

    FAQ

    1. who are we?

    We are based in Guangdong, China, start from 2017,sell to Africa(17.00%),
    Mid East(17.00%),
    Southeast Asia(16.00%),
    Eastern Asia(13.00%),
    South Asia(10.00%),
    South America(8.00%),
    Eastern Europe(4.00%),
    North America(3.00%),
    Northern Europe(3.00%),
    Southern Europe(3.00%),
    Oceania(2.00%),
    Western Europe(2.00%),
    Central America(2.00%),
    There are 5-10 professional workers in HOOHA.


    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you buy from us?
    Drawing Machine,Stranding Machine,Cabling Machine,Extrusion Machine,Bunching Machine

    4. why should you buy from us not from other suppliers?
    1.10 year R&D working experience with over sea service 2.5 big LV/MV cable project over 5 million working experience 3.After service team has 30 country working experience 4. HOOHA team focus on the cable making and use solution supply chain.

    5. what services can we provide?
    Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;
    Accepted Payment Currency:USD,EUR,CNY;
    Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
    Language Spoken:English,Chinese

    6: Do you have a video to show the machine running ?
    A. Yes , we have,our youtube channel :https://www.youtube.com/channel/UCrRUG2MnVoi8rfQ6FK2vYow
