    Automatic Wire Extruder Machine Electri Cable Extrusion Equipment PVC PE PP Copper Wire Insulation Cable

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-50+35/70+40
    Certification : CE/ISO
    Price : USD 46,780-55,320/1 set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 5 sets/1 month
    Delivery Time : 60 Working Days
    • Product Details
    • Company Profile

    Automatic Wire Extruder Machine Electri Cable Extrusion Equipment PVC PE PP Copper Wire Insulation Cable

    Application

    This is designed for insulating low-voltage building wire with various plastic materials including PVC, HFFR, LSHZ.etc. Also it is suit for making power cable, building wire, communcation cable, and so on.


    HH-50MM extrusion machine
    NO.Condctorconductor sectionMax.WireInsulation materialMax.Speed
    1Solid0.5-10mm²10mmPVC,PE,XLPE,HFFR,LSHZ460M/MIN
    2stranded1.0-16mm²
    3Bunched0.5-25mm²


    wire extrusion machine
    NO.Pay offTension controllerMain estrusionCooling troughTractionTake up
    1630MM500KG50+35MMSingle layer Double layer600KG800MM
    2800MM60+35MM1000MM
    31000MM70+35MM1250MM
    41250MM80+35MM1600MM
    90+35MM

    wire extrusion machine
    NO.Model50+35MM60+35MM70+35MM80+40MM90+50MM
    1Pay off typeinitiatire typeinitiatire typeNo-axis magneticNo-axis magneticNo-axis magnetic
    2Screw L/D25:1
    3Out put110KG170KG210KG270KG390KG
    4Main motor15HP30HP30HP40HP50HP
    5Wire diameter1-4MM1.5-8MM2-10MM3-20MM4-45MM
    6Temperature control7 zones8 zones8 zones9 zones9 zones
    7Cooling deviceFolds W type/U typeFolds W type/U typeSingle layer/doubleSingle layer/doubleSingle layer/double
    8Capstan motor3HP4HP5HP7.5HP7.5HP
    9Take upDouble axisDouble axisNo-axis magneticNo-axis doubleNo-axis doublec


    2. After service


    1). Delivery dates: 45 days
    2). Payment: TT or L/C
    3). Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
    4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
    5) .after service phone number online


    3. Factory & Workshop &Warehouse


    Company nameHOOHA Co.,Ltd
    Established2003
    Main productsupcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine and so on.
    Value added serviceInclude factory planning, cable raw material supply,cable equipment layout,cable technology export,customer training and cable testing laboratory construction.
    Factory locationHumen Town,Dongguan City,Guangdong province.
    Manufacturing Center4000 sqm
    ShowroomMore than 2000 sqm.



    Cooperating with German spare parts and production software and using best quality materials and intelligent machine, HOOHA's products maintain high quality with strongly competitive price.


    4. Package


    Two methods: RTA (Ready to assemble, Flat Pack) and fully assembled.

    Plywood frames and Stretch film are used to avoid breakage in transit.


    5. FAQ


    QuestionAnswer
    MOQ1 set
    Lead Time30~40 working days since starting producing.
    Warranty Time1-year quality guarantee for the machine
    Payment Terms30% T/T in advance for production material, 70% in the period of shipment.
    Installation
    (3 choices )
    a. HOOHA's Chinese installation team.
    b. HOOHA's overseas installation co-partners in your country.
    c. DIY Guide: HOOHA supports online guidance.
    How to StartContact us and leave your contact email and phone number.

    6. Why choose us?


    1. We are the cable equipment manufacturer.

    2. Professional engineer,long-term to research and development for to cable equipment .

    3. High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running .

    4. Our machine use the international qualified brand,like siemens ,omron,nsk,lg etc.

    5. Technical support and spare parts service.

    6. Well-experienced in overseas to support customer with technical,training,operating.

    7. Responsible and Good communication and customer service skills,and save time and human cost for customers.

    8.Complete Foreign Trade Team.

    9. Working efficiently,quickly response to customer needs.

    7. Professional and Strong Manufacture and Sells Team:


    Team of HOOHA service
    NameeducationPositionMainly responsible for projectSpecializing in project

    Industry working history

    ( year )

    zanyang XiecollegeGeneral EngineerThe total project design and planningpower cable machine15
    xioahua HucollegeVis general engineerThe total project design and planningnet cable,data cable machine10
    Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25
    xiuwu ChencollegeGeneral EngineerThe total project design and planningcopper drawing machine15
    lixin YuancollegeEngineerThe project design and planningcoppwer wire making technical16
    zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15
    jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7
    xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10
    changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10
    haipin LiUniversityEngineering directorMarketing and salesproject consulting8
    sen YangUniversityEngineering translatorMarketing and salesproject consulting5
