    Building PVC Wire Extruder Machine Magnetic Power Tension Pay Off CE ISO Approved

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : 70+40/90
    Certification : CE,ISO
    Price : 50000-65000 / unit
    Payment Terms : T/T, L/C
    Supply Ability : 20 units/month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Building PVC Wire Extruder Machine Magnetic Power Tension Pay Off CE ISO Approved

    Building PVC Wire And Cable Plastic Extrusion Machine,UZ Market With 10 Years Export


    Application
    It is for insulating,coating,stripping single or two layer wire and cable with extruding PVC,XLPE compound material.
    It is also suit for making power cable, building wire, communication cable,and so on.

    Consisting Components


    Magnetic Power Tension Pay Off35 Vertical Injection Machine
    Straightening WorkbenchElectrical Control Box
    Preheating MachineMovable Water Tank
    Powder MachineAmerican Type Fan
    70mm Extrusion +40 extrusionOD Test Machine
    Printing MachineFixed Water Tank
    Winding MachineMeter Counter Machine
    Spark TesterTake Up Rack

    Technical Parameter:


    Technical Parameter

    Type70mm
    Power380V 50Hz three phrase or customer's requirement
    Main Motor Power

    30KW

    Finish Wire Diameter


    2.0-12.0 mm

    Temperature Control


    8 Zones
    Max Line Speed450m/min
    Rotation Speed110 rpm/min

    Extrusion Capacity


    140kg/hr

    Bobbin Dia


    400-630mm

    Main Parts Function:


    1. Inverter:The speed can be changed from zero to max

    2. Pay-off tension: Control automatically by electricity
    3.Take-up machine uses Polish rod, transverse and distance can be adjusted by plain shaft.
    4. Machine center height: 1 meter
    5. Diameter of screw:70mm, L/D of screw: 26/1. Material: 38 CrMoAiA


    6.The surface of screw is carburized and quenched, electroplated with hard cr.
    7. Inside diameter of screw tube: 70mm. Material: 38 CrMoAiA,
    8.The surface is carburized and quenched.
    9.The material of insulation are PVC, PE
    10. Production direction: Pay-off on the left. Take-up on the right. Customer's requirement

    11. Color of production line is light blue(automobile finish ), safe cover is yellow OR customer's requirement
    12. PROMOT SWITCH counter, set length freely.
    13. Automatically stop: When the counter has reached to your desired length, the Take up will stop automatically, if wire breaks abnormal and self-actuating brake

    Building PVC Wire Extruder Machine Magnetic Power Tension Pay Off CE ISO Approved
    Q:What is HOOHA service when we work together ?

    HOOHA Group provide the series solution for the layout design of cable plant, machine matching, shipping and installation. It means you only spend less money on machine. You can enjoy such services and get more money.


    1. HOOHA is a manufacturing and trading combo for wire and cable making machine .

    2. Professional engineer,long-term to research and development for to cable equipment .

    3. High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running .

    4. Our machine use the international qualified brand,like siemens ,omron,nsk,lg etc.

    5.Technical support and spare parts service.

    6.Well-experienced in overseas to support customer with technical,training,operating.

    7. Responsible and Good communication and customer service skills,and save time and human cost for customers.

    8. Complete Foreign Trade Team.

    9. Working efficiently,quickly response to customer needs.

    1.Who are we?
    Hooha company Limited is based in Hongkong, china.Factory is located in dongguan,China.Established in 2003, with 19 years of experience in wire and cable field trade.It only takes 1 hour from our company to guangzhou/shenzhen airport.

    2.How can we guarantee quality?
    1.Online inspect facotry,production,shipment,and aftersales services.
    2.pre-production sample before mass production.
    3.Highstandards and strict requirements, key accessories of cable equipment only use imported parts.
    4.Mechnical parts gurantee 12months, elcctrical parts 12 months.
    5.online communication,remote assistance,solve customer problem 24 hours,when the problem can not solved online,we will dispatch engineer to go aboard to the problem on-site for the customer.
    3.What can you buy from us?
    1.material for wire and cable
    2.turkey project for wire and cable
    3.extrusion line/bunching/twisting
    machine for wire and cable
    4.accessorries for cable equipments

    4.How long is your delivery time?
    1.Generally, 3-7 days for goods in stock
    2.30 days for goods after realsing order.
    3.project will take 60-90 days

    5. Will the price be cheaper if the order is placed in bulk?
    Yes,Of course,it will make 10%-12% discount

    6.What services can we provide?
    1.Plant solution and machine design.
    2.technical support at machines and cable
    3.Installtion and commmsioning,after sales service.
    4.Packaging customization 5.Customized,saving 10%-20% year-on-year cost

    7.HOOHA cable equipment technical advantages
    1.In order to ensure the high quality of products,we start from ensuring the accuracy of accessories, and the main accessories of products(Casing, end cover, shaft and wheel) they are all manufactured by CNC machining center,The main purchased parts are NSK Bearings from Japan,American gates belt,taiwan TTO Fluoro rubber oil seal,The working efficiency of the equipment is improved, the noise is reduced, and the service life of the equipment is extended to more than 10 years.
    2.High precision dynamic balancing of all equipment rotors,The dynamic balance level is G1, reducing the unbalance to less than 1G, and the long-term operation is safe and reliable.
    3.The bearing adopts double row cylindrical roller bearing and double row self-aligning roller bearing,compared with
    the deep groove ball bearing, the bearing has high fatigue strength, long service life, stable operation and small vibration.
