    9.5mm Aluminum Wire Drawing Machine Sliding Type Cable Drawing Machine

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : 13 Dies
    Certification : ISO,CE
    Price : 178,950 -249,500 USD/unit
    Payment Terms : T/T, L/C
    Supply Ability : 10 units/month
    Delivery Time : 40 working days
    • Product Details
    • Company Profile

    9.5mm Aluminum Wire Drawing Machine Sliding Type Cable Drawing Machine

    9.5mm Aluminum Wire Drawing Machine Sliding Type Aluminum Rod Breakdown


    Application

    This aluminium rod breakdown machine adopts continue casting direct rolling technology to produce Al-Mg-Si alloy rod that concluding Ø9.5 mm, Ø12 mm, Ø15 mm 3-different diameter type. The raw materials of this rod are pure aluminum ingots or electrolytic aluminum liquid or aluminum alloy


    Compositions of drawing equipment


    NameQty
    1.Cantilever Pay-off shelf1 set
    2.Main drawing machine1 set
    3.Tension controller1 set
    4.630 Double spoolers1 set
    5.Electrical cabinet1 set
    6.Operation panel1 set
    7.Gear Oil system (Pump+Cooler)1 set
    8.Spare parts1 set

    II. Main technical parameters

    1.Inlet9.5mm (Inlet wire straightening function is provided)
    2.Outlet1.7mm-4.2mm (Final wire cleaning function is provided)
    3.Diameter of capstans450mm
    4.Speed1500m/min, capacity say 1.7mm, 540kg per hour
    5.Slip ratio1.4-1.2 decrease
    6.Quantity of capstan13
    7.CapstanTungsten carbide (With wire threading function)
    8.Quick dies changeAvailable / Require less dies
    9.Main motorDC250KW, with DC Controller
    10.Fix speed motorDC75KW, with DC Controller
    11.GearChangeable
    12.Noises of machine≤85 db
    13.Protection coverMotor transmission cover installed
    14.OthersCooler for Gear oil is provided
    15.OthersAll main pipes are provided
    16.Others Gear oil recycling complete system is provided, including: Pump, Gear oil tank, Pipes, Oil Pressure Gauge, Signal wire. When lack of oil, machine will auto stop.
    17.Others Cooler for Lubrication oil , no need. You need prepare one Underground Tank for Lubrication Oil recycle.

    9.5mm Aluminum Wire Drawing Machine Sliding Type Cable Drawing Machine

    9.5mm Aluminum Wire Drawing Machine Sliding Type Cable Drawing Machine


    1.Who are we?
    Hooha company Limited is based in Hongkong, china.Factory is located in dongguan,China.Established in 2003, with 19 years of experience in wire and cable field trade.It only takes 1 hour from our company to guangzhou/shenzhen airport.

    2.How can we guarantee quality?
    1.Online inspect facotry,production,shipment,and aftersales services.
    2.pre-production sample before mass production.
    3.Highstandards and strict requirements, key accessories of cable equipment only use imported parts.
    4.Mechnical parts gurantee 12months, elcctrical parts 12 months.
    5.online communication,remote assistance,solve customer problem 24 hours,when the problem can not solved online,we will dispatch engineer to go aboard to the problem on-site for the customer.

    3.What can you buy from us?
    1.material for wire and cable
    2.turkey project for wire and cable
    3.extrusion line/bunching/twisting
    machine for wire and cable
    4.accessorries for cable equipments

    4.How long is your delivery time?
    1.Generally, 3-7 days for goods in stock
    2.30 days for goods after realsing order.
    3.project will take 60-90 days

    5. Will the price be cheaper if the order is placed in bulk?
    Yes,Of course,it will make 10%-12% discount

    6.What services can we provide?
    1.Plant solution and machine design.
    2.technical support at machines and cable
    3.Installtion and commmsioning,after sales service.
    4.Packaging customization
    5.Customized,saving 10%-20% year-on-year cost


    7.HOOHA cable equipment technical advantages
    1.In order to ensure the high quality of products,we start from ensuring the accuracy of accessories, and the main accessories of products(Casing, end cover, shaft and wheel) they are all manufactured by CNC machining center,The main purchased parts are NSK Bearings from Japan,American gates belt,taiwan TTO Fluoro rubber oil seal,The working efficiency of the equipment is improved, the noise is reduced, and the service life of the equipment is extended to more than 10 years.
    2.High precision dynamic balancing of all equipment rotors,The dynamic balance level is G1, reducing the unbalance to less than 1G, and the long-term operation is safe and reliable.
    3.The bearing adopts double row cylindrical roller bearing and double row self-aligning roller bearing,compared with
    the deep groove ball bearing, the bearing has high fatigue strength, long service life, stable operation and small vibration.
