300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine

    Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers

    Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers
    • Buy cheap 300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine from wholesalers

    300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HOOHA-300
    Certification : CE/ISO
    Price : USD 18500
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 20 sets/month
    Delivery Time : 60 working days
    • Product Details
    • Company Profile

    300P Copper Wire Bunching Machine For Fine Wire Bunching High Speed Wire Twisting Machine

    Copper Wire Bunching Machine


    1. Application of the equipment


    It is suitable for stranding of the copper wires with more than seven strands, such as electronic wires, power wires, bare copper wires, network wires, etc.



    2. The specifications of 300 bunching machine


    Model No.300
    Copper wire Dia.0.05-0.25mm
    Twisting sectional area0.035-0.45mm2
    Max. main shaft speed3000rpm
    Twisting pitch range2.00-17.17mm
    Traversing typetransverse and distance can be adjusted by bearing bransverse
    Bobbin loading & unloading typehydraulic type
    Bobbin Dia.300mm
    Brake systemmagnetic brake
    Motor power4kw
    Main shaft center height630mm
    Auto stop unitauto stop when reach setting length, and wire broken inside and outside
    Operating directionleft/right hand machine

    3. Timely delivery


    Our shipments are very timely and the process is very systematic.



    4. Special Service


    (1) HOOHA GROUP provide a series of solution based on the real need of our customers in the field of wire and cable making machine. We offer the layout design of cable plant, machine shipping and installation, and subsequent equipment operation training and so on. It means you only spend less money on machine and can enjoy such services and save time.We are committed to providing you with cost-effective products to reduce your concerns.


    (2) Throughout the entire trade operation process, we strictly control every handover step with highly efficiency in order to guarantee the best products being sent to our customers within the required time.


    (3)Our corporate culture is growing together with customers. Helping customers achieve greater development through cooperation with us is what we have been doing.


    5. FAQ1:What is your product brand to support different customer in market ?


    All configurations are first-rate, we don't like to talk about configuration because, as a company that considers quality first, a first-class brand is its basic requirement.

    Motor: Siemens

    Inverter : available to Japan Yaskawa, Siemens, America Emerson

    Temperature Control Meter : Japan RKC, Omron

    PLC : German Siemens , Japan Misubishi

    Auxiliary Relay: Japan Omron

    Ammeter and Voltmeter: Taiwan Risesun

    Indicator, Switch and Button : Taiwan TEND

    Contactor: Taiwan Shihlin ,Schneider

    Relay: Japan Omron

    Line Speed Meter: Taiwan FOTEK/Yangming

    Bearing : NSK, SKF


    6. FAQ2:Does your team have rich experience?


    1). Our Pre-sales team:machine designers ( 5 member) and wire and cable engineers(5) are over 15 years experience

    2). Dedicated service team:who is specialized in wire and cable engineering field (10) , are over 8-10 years experience

    3). After service team:electricity engineers (10), mechanical Engineers(8),software engineer(5) are over 10 years experience

    4). Production self-inspection team:production self-inspection engineers(5) , are over 15 years experience.


    Name

    education

    Position

    Mainly responsible for project

    Specializing in project

    Industry working history

    zanyang Xie

    college

    General Engineer

    The total project design and planning

    power cable machine

    15 years

    xioahua Hu

    college

    Vis general engineer

    The total project design and planning

    net cable,data cable machine

    10 years

    Chnaghong Cheng

    college

    Engineer

    Drawings and after-sales service

    Teflon,Optical fiber cable machine

    25 years

    xiuwu Chen

    college

    General Engineer

    The total project design and planning

    copper drawing machine

    15 years

    lixin Yuan

    college

    Engineer

    The project design and planning

    coppwer wire making technical

    16 years

    zhenghai Qiu

    college

    cable engineer

    After service

    cable making and cable factory management servie

    15 years

    jinxin Liu

    college

    Marketing engineer

    After service

    electrical engineer

    7 years

    xingguo Tang

    High school

    Electrical engineer

    After service

    electrical engineer

    10 years

    changqiang Li

    High school

    Maintain engineer

    After service

    machina maintain and install service

    10 years

    haipin Li

    University

    Engineering director

    Marketing and sales

    project consulting

    8 years

    sen Yang

    University

    Engineering translator

    Marketing and sales

    project consulting

    5 years



    7. FAQ3:What do our company focus on?


    1. Quality, our engineers work with service colleagues.We are committed to enabling engineers to learn more about customer feedback from the service team.

    2. Customers' comfortable purchasing experience.We pay attention to the actual needs of customers, and hope to bring customers high-efficiency products and intimate service, our services cover pre-sales and after-sales, committed to let customers save time and cost, and reduce worries

    3.Customers' success.We not only focus on the sales of products, but also pay attention to the development of our customers. We pursue growing together with customers by providing long-term support and suggestions to help them achieve success.

    4.Supply more environmentally friendly products.

    5.Give back to the community and help more people.


    8. Company profile


    Company nameHOOHA Co.,Ltd
    Established2003
    Main productsUpcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine and so on.
    Value added serviceInclude factory planning, cable raw material supply,cable equipment layout,cable technology export,technical support and operation training and cable testing laboratory construction.
    Factory locationHumen Town,Dongguan City,Guangdong province.
    Manufacturing Center4000 sqm
    ShowroomMore than 2000 sqm.

    9. Choose Us


    1. We are the cable equipment manufacturer.

    2. Professional engineer team with long-term research and development in the field of cable equipment.

    3. Provides high frequency capacity manufacturing machines. Keep the machine running all day.

    4. Our machine use the international qualified brand components,like Siemens,Omron,Nsk,lg etc

    5. Technical support and spare parts service.

    6. Rich experience in overseas technical training and operation training.

    7. Professional and responsible team to ensure efficient communication,help to save time and human cost for customers.

    8. Systematic experienced foreign trade team to ensure service quality.

    9. Working hard to meet customers’ needs.


    10. Detailed address


    Add: 3 rd Floor, Building D, No.38 Houhu Road, Humen Town, Dongguan City, Guangdong Province,China


    Hongkong airport to Humen by boat 2 hours
    Guangzhou airport to Humen by car 2 hours
    Shenzhen airport to Humen by car 1 hour
    Guangzhou South high speed train station to Humen 20 minutes
    Shenzhen North high speed train station to Humen 20 minutes
