    PVC Wire Manufacturing Machine Building Cable Making PLC Siemens

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-70+35/80+35/90+45MM
    Certification : CE/ISO
    Price : US$53470-56890/1set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 18set/1 month
    Delivery Time : 30 Working Days
    • Product Details
    • Company Profile

    PVC Wire Manufacturing Machine Building Cable Making PLC Siemens


    High Speed PVC Wire And Cable Machinery Building Cable Making , 380 Voltage


    1. PVC insulated flexible single copper conductors


    1. Construction : Solid Bare Copper Conductor stranded , PVC Insulated (1,2,3 cores)


    A. Solid Bare Copper Conductor stranded --- 1000-1250mm bow strander machine


    B. PVC insulated --- 80 +35 cable extrusion machine


    Application : Suit for PVC /PE plastic extrusion , maily used in fire alam cable , electrical wire , house wire ,

    data cable , network cable etc insulation


    2. Machine devices as reference


    1. Magnetic Power Tension Pay Off stand
    2. Dancer / straigter
    3. 80mm Main extruder
    4. Automated loader & dryer
    5. Auto central crosshead
    6. Single /Double layer Moving trough
    7. Main cooling trough
    8. Water wiper
    9. Digital Diameter controller
    10. Mark printer( selectable )
    11. Accumulator
    12. Capstan
    13.15KV Spark tester
    14. Meter counter
    15. Dual shaft type Take up
    16. Master control cabinet

    17. 35mm strip extruder machine


    Model:HOOHA-80+35Consisting Components
    Pay off bobbin size:400-630 mmPay off stand1
    Screw size:80mmDancer1
    Motor control:30 kw inverter80mm extruder1
    Screw speed:110 rpmloader & dryer1
    Output capacity:250 kg/hrCrosshead1
    Max. accumulating length200 mMoving trough1
    Finished cable diameter2.0---20 mmMain cooling trough1
    Max. line speed:200m/minWater wiper1
    Diameter controller1
    Mark printer1
    Accumulator1
    Capstan1
    Spark tester1
    Meter counter1
    Take up1
    Control box1


    HOOHA-extrusion line
    NOModelScrewMain Extruder OutputMain extruder Motor PowerCo-Extruder OutputCo -extruder
    Motor Power
    DiaL/DRotation
    (mm)RatioSpeed
    (r/min)(kg/h)(kw)(kg/h)(kw)
    130302540~10010~127.500
    250502640~10060~701500
    350+502640~10060~701510~123.7
    465652640~10080~1002200
    570+35702640~100110~1303010~123.7
    670+40702640~100110~1303030~4011
    780802640~100180~2003700
    880+40802640~100180~2003730~407.5
    980+50802640~100180~2003760~7011.25
    1090902630~90240~2605500
    1190+50902630~90240~2605530~407.5
    121001002630~903905500
    131201202630~906409000
    141501502630~9086011000

    PVC Wire And Cable Machinery Building Cable Making , PLC Siemens


    5. After service


    1). Delivery dates: 45 days
    2). Payment: TT or L/C
    3). Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
    4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
    5) after service phone number online


    6. Factory & Workshop &Warehouse


    Company nameHOOHA Co.,Ltd
    Established2003
    Main productsupcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine and so on.
    Value added serviceInclude factory planning, cable raw material supply,cable equipment layout,cable technology export,customer training and cable testing laboratory construction.
    Factory locationHumen Town,Dongguan City,Guangdong province.
    Manufacturing Center4000 sqm
    ShowroomMore than 2000 sqm.



    Cooperating with German spare parts and production software and using best quality materials and intelligent machine, HOOHA's products maintain high quality with strongly competitive price.


    Automatic Cable Wire Machine Extrusion Equipment Japan NSK Bearing Siemens Inverter

    Automatic Cable Wire Machine Extrusion Equipment Japan NSK Bearing Siemens Inverter

    7. Package


    Two methods: RTA (Ready to assemble, Flat Pack) and fully assembled.

    Plywood frames and Stretch film are used to avoid breakage in transit.


    8. FAQ


    QuestionAnswer
    MOQ1 set
    Lead Time30~40 working days since starting producing.
    Warranty Time1-year quality guarantee for the machine
    Payment Terms30% T/T in advance for production material, 70% in the period of shipment.
    Installation
    (3 choices )
    a. HOOHA's Chinese installation team.
    b. HOOHA's overseas installation co-partners in your country.
    c. DIY Guide: HOOHA supports online guidance.
    How to StartContact us and leave your contact email and phone number.
