    380v Wire Extrusion Machine , Power Cable Making Equipment CE ISO Certification

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-80+35MM
    Certification : CE/ISO
    Price : US$57,000-70,000/1set
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 5set/1 month
    Delivery Time : 25-35Working Days
    • Product Details
    • Company Profile

    380v Wire Extrusion Machine , Power Cable Making Equipment CE ISO Certification


    Wire And Cable Machinery, Algeria Power Cable Making Equipment , Wire And Cable Extrusion Machine


    1. Application :


    Suit for PVC /PE plastic extrusion , maily used in fire alam cable , electrical wire , house wire , data cable , network cable , building cable etc insulation and sheath


    2. Machine devices as reference


    1. Pay off stand
    2. Dancer / straigter
    3. 80mm extrusion machine
    4. Automated loader & dryer
    5. Auto central Crosshead
    6. Single /Double layer Moving trough
    7. Main cooling trough
    8. Water wiper
    9. Digital diameter controller
    10. Mark printer( selectable )
    11. Accumulator
    12. Capstan
    13.15KV Spark tester
    14. Meter counter
    15. Dual shaft type Take up
    16. Master control cabinet OF PLC

    18.35mm strip extruder machine / 50 extrusion machine (co-extrude)


    3. MAIN PARTS BRAND


    1. Motor: Siemens
    2. Inverter: Germany-Siemens or YASKAWA Japan
    3. Electric equipment: Siemens and Omron
    4. Bearing: NSK from Japan
    5. Belt: Mitsubishi


    HOOHA-extrusion line
    NOModelScrewMain Extruder OutputMain extruder Motor PowerCo-Extruder OutputCo -extruder
    Motor Power
    DiaL/DRotation
    (mm)RatioSpeed
    (r/min)(kg/h)(kw)(kg/h)(kw)
    130302540~10010~127.500
    250502640~10060~701500
    350+502640~10060~701510~123.7
    465652640~10080~1002200
    570+35702640~100110~1303010~123.7
    670+40702640~100110~1303030~4011
    780802640~100180~2003700
    880+40802640~100180~2003730~407.5
    980+50802640~100180~2003760~7011.25
    1090902630~90240~2605500
    1190+50902630~90240~2605530~407.5
    121001002630~903905500
    131201202630~906409000
    141501502630~9086011000
    NOProduct sizeCrossheadHeating Zones of cylinder
    Line Speed
    (mm)(m/min)(kw)
    10.15~0.800.2~1.010~600FixedSingle4/6(U7)4 zone 2.4kw
    20.5~4.00.8~5.010~600FixedSingle4/6(U7)4 z * 2.4kw
    30.5~4.00.8~5.010~600FixedSingle+ stripe4/6(U7)4 z * 2.4kw
    41.0~102.0~1210~600Fixed /manualSingleU7~U144 z * 3.0kw
    51.6~122.0~1510~700Fixed /manualSingle+ stripeU7~U145 z * 4.0kw
    61.6~122.0~1510~700Fixed /manualSingle+ stripe/skinU7~U145 z * 4.0kw
    72.0~203.0~2510~700Fixed /manualSingleManual centering5 z * 3.6kw
    82.0~203.0~2510~700Fixed /manualSingle+ stripe/skinManual centering5 z * 3.6kw
    92.0~203.0~2510~700Fixed /manualSingle+ stripe/skinManual centering5 z * 3.6kw
    105.0~359~3010~700Fixed /manualSingleManual centering5 z * 4.5kw
    115.0~3510~3310~700Fixed /manualSingle+skinManual centering5 z * 4.5kw
    124.0~305.0~5010~220manualSingleManual centering5 z * 4.5kw
    134.0~3010~8010~150manualSingleManual centering5 z * 4.5kw
    144.0~3015~12010~100manualSingleManual centering5 z * 4.5kw




    4. After service

    1). Delivery dates: 45 days
    2). Payment: TT or L/C
    3). Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
    4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
    5) after service phone number online

    5. Why choose us?

    1.We are the cable equipment manufacturer.
    2.Professional engineer,long-term to research and development for to cable equipment .
    3.High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running .
    4.Our machine use the international qualified brand,like siemens ,omron,nsk,lg etc.
    5.Technical support and spare parts service.
    6.Well-experienced in overseas to support customer with technical,training,operating.
    7.Responsible and Good communication and customer service skills,and save time and human cost for customers.
    8.Complete Foreign Trade Team.
    9.Working efficiently,quickly response to customer needs.
