Electric Driven 10mm Cable Insulation Machine

Ask Lasest Price
Brand Name :	HOOHA
Model Number :	HH-50/70/80/90/120MM
Certification :	CE/ISO
Price :	US＄39880-42880/1set
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	10set/1 month
Delivery Time :	25 Working Days

Add to Cart

Product Details
Company Profile

Electric Driven 10mm Cable Insulation Machine

High Price Quality Ratio Wire And Cable Insulation Making Machine

1. Technical Parameters

HOOHA wire and cable extrusion machine
Model	HOOHA 50+30	HOOHA 70+35
Model	HOOHA 50+30	HOOHA 70+35	HOOHA 90+40
Pay off bobbin	PN300-500	PN400-630	PN500-800
Screw diameter	50+30(sub-extruder)	70+35( sub-extruder )	90+40( sub-extruder )
Screw L: D	25:1	25:1	25:1
Capacity (kg/hr)	60	150	280
Main motor	15 HP	30 HP	50HP
Wire diameter	Φ0.8-2.5	Φ3.5-6.0	Φ4.0-15.0
Temp control	8 zone	10 zone	12 zone
Cooling device	U type single layer(18m)	U type single layer(30m)	U type single layer(40m)
Pulling power	3HP	5HP	10HP
Accumulator	horizontal	horizontal	horizontal
Max accumulation	250m	200m	150m
Running speed	MAX500	MAX400	MAX350
Taking up type	Double bobbin	Double bobbin	Double bobbin
Taking up bobbin	PN300-500	PN400-630	PN500-1000
Electricity control	Inverter +PLC(for elected)	Inverter +PLC(for elected)	Inverter +PLC(for elected)

Electric Driven 10mm Cable Insulation Machine

2. Application

Applied to BV,BVV,BVR,RV,Nylon sheath,and halogen-free environment-friendly building wire and power cable.

Finished wire or cable diameter range: 0.5-25 mm. We can provide the most suitable equipment solution as per

your wire and cable size you will produce.

Electric Driven 10mm Cable Insulation Machine

3. Famous Brands Parts:

to ensure reliable quality and performance.
Motor: Dongguan Motor, Teco, ABB, Siemens
Inverter: Japan Yaskawa, Siemens, Taiwan Teco
Temperature Control Meter: Japan RKC
Auxiliary Relay: Japan Omron
Ammeter and Voltmeter: Taiwan Risesun
Indicator, Switch and Button: Taiwan TEND
Contactor: Taiwan Shihlin
Line Speed Meter: Taiwan FOTEK
Bearing: NSK, SKF

Electric Driven 10mm Cable Insulation Machine

4. Package and Shipping

Two ways: RTA (Ready to assemble, Flat Pack) and fully assembled.
Well packed with pe film and plywood frame to avoid damage in transit.

FOB shengzhen port or CIF are both available.

Electric Driven 10mm Cable Insulation Machine

4. After service

1).Free online consultancies service and installation guidance.
2).Overseas on-site installation, pre-production testing, operation instruction and skill training.
3).Long-time maintaining, reconstruction and upgrade services of the overall machines.
4).Extended service, including raw material purchasing, accessory suggestions and technical advice.

5. Company Profile & Workshop & Warehouse

Company name	HOOHA Co.,Ltd
Established	2003
Main products	upcast and continuous casting machine,wire extrusion machine,wire stranding machine,wire drawing machine,test machine etc.
Value added service	factory construction advice, cable raw material supply, cable equipment layout, cable technology support, operation training and cable testing laboratory construction.
Factory location	Humen Town,Dongguan City,Guangdong province.
Manufacturing Center	4000 sqm
Showroom	2000 sqm

▶With more than 20 years experience in cable machinery field, insisting on deep cooperation

with Chinese leading cable equipment companies and cable manufacturer, Hooha has always

been providing advanced cable production solutions and services to our global customers.

▶Now although effected by CONVID-19, we keep working hard to provide strong support to

our customers' cable and wire project. We do pre-production test for the machines before shipping

and shot detailed video for installation and operation guidance, helped our customers' project run

smoothly.

6. Why Choose us?

Reliable Products:
1.Over 20-year experienced engineer team in cable and wire equipments field to guarantee professional solution and

first-rate quality products.

2.Adopting famous brand parts such as Siemens, Yaskawa, Omron, Emerson to ensure reliable using of our products.

3.We check every detail of the machines and do pre-production test before delivery to eusure products quality.

All-round Service:
1.Our professional engineer team had over 5 years experience working overseas in cable and wire field, will provide various

technologies to support our customers, including overseas on-site installation guidance, talent training, long-term technological

updating services,etc.

2.Our rich-experience sales team will advice your concerns professionally with rigorous working attitude and high communication

efficiency.

Full automatic CE Certification 380V Voltage silicone rubber wire cable extrusion machine line

7. FAQ

Q1:Can you arrange the installation or any guidance?
A: We have video instruction for on-line installation guidance.
Although effected by the pandemic covid-19, we have

supported more than 10 customers to run the machines via on-line
support. Overseas on-site installation service is

also availabel once covid-19 get controlled.

Q2:Could you arrange the operation education?
A:We have operation book and on-line video operation guidance. Our
professional engineers will provide on-line

response on operation timely. If needed, we can also visit your
factory and provide on-site training on operation.

Q3:What is the your difference with other supplier?
A:What we could offer to our customers is not only the machine,
also we could offer: factory design,

production process design , QC control and, on-site installation,
operation training, technology upgrading

and raw material offering. We have cooperated with global customers
in more than 30 countries.

Q4:What's the payment terms?
A:T/T, L/C are both available.

Q5:How long is your product warranty?
A: One year. After that we will still provide maintaining and
repairing with charge in the whole life.

Q6: Do you have a video tips for the machine running ?
A. Yes , we have. You can learn more about our company and machines
via our youtube channel : tiezhong chi or

HOOHA WIRE MACHINE.
