    10 MW Flammability Test Apparatus Heat Release Rate Test Device Microcomputer Controlled

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-ZY6257
    Certification : CE/ISO/CCC
    Price : US$193900-194500/1set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1set/1 month
    Delivery Time : 30 Working Days
    • Product Details
    • Company Profile

    10 MW Flammability Test Apparatus Heat Release Rate Test Device Microcomputer Controlled

    HH-FT-8373 Vertical Test Machine for Fire Resistance of Building Elements

    Application

    Applicable to buildings and large complexes (including locomotive vehicles, vehicles, warehouses and components) and extensive fire resistance test verification for raw materials, buildings and physical models


    General Parameters


    1. The whole machine consists of standard test room, standard ignition source, cone collector, gas analyzer, exhaust pipe, flue gas cooler, fan and measuring device.

    2. Standard test room:

    Dimensions: long 6000 plus or minus 50mm, width 4800 + 50mm, high 2400 + 50mm

    3. The door of the standard test room is located at the center of the wall with a short side of 4800*2400mm wall, and the floor roof has no air vents. The size of the door is 800 plus or minus 10mm, and the height is 2000 plus or minus 10mm.

    4. The test room is composed of non-combustible materials with a density of 500-800kg/M3 with a thickness of 25mm.

    The center of the north wall of the combustion chamber has a gate of 0.8m-wide x2m, and a 2m x2m viewing window on the east wall.

    An electron is placed at the geometry center of the combustion chamber. The measuring range is 0--500 kg, and the measurement accuracy is 0.001kg, which can be used to measure the loss of the combustor during the combustion process.

    Southwest corner of the room set up total fire, firearms, the total fire use square openings of gas total firearms within the total is divided into two layers, the lower is the grit, the upper is fine sand, separated with wire mesh in the middle

    During the test, the combustion of the sample and the combustion products are discharged from the exhaust pipe.

    Carbon monoxide range: 0-1%, measuring accuracy plus or minus 0.1%

    Carbon dioxide (CO2) measurement range 0-10% and repeatability < 1%;

    High precision pressure regulating valve, adjusting standard pressure;

    The glass rotor flowmeter regulates the flow of combustion jet.

    Smoke density: light source, halogen lamp, convex lens, silicon photocell 4

    Temperature measurement: 5m thermoelectric pot 7, 0.25mm thermoelectric pot 5.



    Packaging & Shipping

    Streatchable PE film wrapped, wooden frame packed, loaded into container for shipping. Special packaging way as per discussed.


    Our Advantages


    FAQ

    Q1:What is your main brands for the electrical and mechanical parts?
    A:Oversea famous brand such as German siemens motor, Japanese nsk bearing and yaskawa inverter etc.
    Q2:What is your difference with other suppliers?
    A:What we could offer to other customer is not only the machine itself, also we could offer: factory design, production process
    design , QC control, talent training, assist machine and raw material offering .

    Q3:What's the payment terms?
    A:T/T,30% deposit and 70% balance before delivery, can be negotiable also.

    Q4:How long the guarantee ?
    A: One year and charge for repair in the whole life.

    Q5: Do you have a video to show the machine running ?
    A. Yes , we have,our youtube channel : tiezhong chi.
